The ET101-07SC runs on 230 V AC ±15% (50/60 Hz / 1-phase) at up to 32 A through a 5 m Type 2 tether. Wi-Fi + Bluetooth with OCPP 1.6J, app control, RFID and plug-and-charge, OTA updates by app, dynamic load balancing and solar charging. 30 mA Type A + 6 mA DC leakage protection is built in; PEN protection, CT sensors and the LCD variant are specified separately.
Key features
- IEC / EN 61851-1 Mode 3 AC charging
- ET101 family offered at 7, 11 and 22 kW
- Built-in AC 30 mA + DC 6 mA leakage protection (RCMU)
- Emergency stop button (auto hold)
- High-accuracy metering IC
- LCD display (optional)
- Dynamic colourful LED charging indication
- Wi-Fi + Bluetooth connectivity
- RFID card / QR-code scan / app remote control
- IEC 62196-2 Type 2 tether cable, 5 m (holster included)
- Input cable 1 m (optional)
- OCPP 1.6J core
- Dynamic Load Management (DLM)
- OTA firmware update
- App remote start / reservation / current setting
- Solar energy charging support
- 5.8 GHz radar + courtesy light (optional)
- Reinforced engineering plastic housing (ABS + PC)
- IP65 / IK10 enclosure rating (LCD version IK08)
- PEN-F protection support (optional for UK)
- Compatible with mainstream EV models
